| Description of the design |
Dispersive dichroic mirror |
| Type |
Mirror |
| Subtype |
High(positive)-dispersion mirror |
| Nominal GDD |
450 fs2 |
| First working range |
|
| Angle of Incidence in degrees |
5 ° |
| Angle of Incidence in degrees (double-angle) |
- |
| Polarization regime (primary spectral range) |
p |
| Spectral category |
IR |
| Spectral working range low end |
2600 nm
|
| Spectral working range high end |
3200 nm
|
| Central wavelength |
2900 nm
|
| Minimum reflectance |
99 % |
| Maximum reflectance |
- |
| Minimum transmission |
- |
| Second working range |
|
| Second spectral working range low end |
1500 nm |
| Second spectral working range high end |
1630 nm |
| Polarization regime (second working range) |
p |
| Minimum reflectance |
0 % |
| Minimum transmittance |
99 % |
